System:
3 way floorstanding vented box loudspeaker.
Cabinet:
Lute shape design, combination of sandwich
construction obtained using hand selected
wood layers and solid maple, quality graded
and oriented for carefully optimized resonances
control.
Tweeter:
25 mm ultra dynamic ring radiator-driver,
neodymium magnet system.
Mid-Range:
120 mm cone driver with Symmetric Drive
Motor System and selected black wood
fiber cone, high resolution, treated for
break-up control.
Dynamic linear suspension, neodymium
magnet system. Designed synergistically
with its vented acoustic chamber. Sonus
faber exclusive.
Woofers:
150 mm lightweight Aluminum/Magnesium
alloy cone drivers.
Ultra dynamic performance and linearity.
Special coaxial anti-compressors are used,
designed to remove cavity resonance and
distortions.
Cross-over:
Non-resonant third order design, optimized
phase characteristics for optimal space/time
performance, cross-over points 450 Hz
– 3.600 Hz.
Frequency response:
50 Hz – 30.000 Hz, tuning ports included.
Sensitivity:
91 dB SPL (2.83 V/1m).
Nominal impedance:
4 ohm.
POWER HANDLING:
50W – 200W, without clipping.
Finish:
Natural maple or light graphite multicoated with medium gloss ecologically sensitive lacquer.
Dimensions:
215 x 635 x 380 mm (HxWxD).
Weight:
18.5 Kg – net weight / 22.3 Kg – shipping weight.
OPTIONAL DEDICATED STAND:
Dimensions: 420 x 455 x 310 mm (HxWxD).
Weight: 10.2 Kg – net weight / 13 Kg – shipping weight.
TOTAL DIMENSIONS:
640 x 630 x 380 mm (HxWxD).
