Each of the five drivers is working in a separate cabinet, and can work without being affected by the others. Both of the bass-woofers, ( via supplied port stops ), can be adjusted individually to change the tuning frequencies (in order to handle difficult room interactions). The double layered interior with a cabinet thickness up to 60 mm, both strutted and interlokked, excels through a combination of high absorption, vibration, and resonance control. Through this extreme expenditure and design consideration, cabinet noises are eliminated.
technical data:Network: 18 / 6 dB Impedance - linearized
Woofer: 2 x 220 mm Aluminium-Cone SCAN SPEAK
Midrange: 2 x 130 mm Ceramic Cone THIEL ACCOUTON
Tweeter: Air Motion Transformer MUNDORF
Continuous power RMS: 350 Watts
Maximum power handling: 500 Watts
Frequency range: 23 - 35 000 Hz.
Sensitivity (2,83 V/m): 92,5 dB
Cut frequency: 200 / 3200 Hz
Suitable for ampl.: 4 - 8 Ohms
Impedance: 4 Ohms
Weight: 90 kg
Cabinet: plural layered interior, struted and interlocked cabinet Realwood finish / piano lacquered
Dimensions: Hight: 1580 mm / Width: 330 mm / Depth: 490 mm
Utility: Speaker Base, Spikes included
